TOTAL ROTATION ANGLE
ROTATION TORQUE
SHAFT STOP SERENGTH
SWITCH WORKING ANGLE
SWITCH WORKING TORQUE
SWITCH CIRCUIT
SHAFT LEVER STRENGTH
ROTATION/SLIDING LIFE
SWITCH LIFE |
260°±5°
20~200gf.cm
more than 3kgf.cm/min
30°±10°
70~400 gf.cm
S.P.S.T
pulling pushing more than 5kg
more than 15,000 cycles
more than 10,000 cycles |
RETED WATTAGE
RATED VOLTAGE
INSULATION RESISTANCE
DIELECTRIC
SWITCH CONTACT RESISTANCE
SWITCH RATING
TOTAL RESISTANCE&TOLERANCE
|
linear taper(B) Other
taper
0.1W 0.05W
200V 150VDC
more than 50mΩ at DC500V
500VAC.1minute
less than 20mΩ
12VDC.1A
5k-2mΩ ±20%(more than 1m±30%) |
|
