ELECTRICAL SPECIFICATIONS   　 　 　 　
　 TOTAL RESISTANCE&TOLERANCE.................................   5k-2M±20%(MORE THAN 1M±30%)
　 RAEED WATTAGE.................................................................   OTHER THAN B CURVE 0.125 W
　
B CURVE 0.06 W
　 RATED VOLTAGE..................................................................   OTHER THAN B CURVE 200 V
　
B CURVE 150 V
　 RESIDUAL RESISTANCE....................................................   BETWEEN TERMINAL 1/2     10Ω
　
　
2/3     10Ω
MAX
　 INAULATON RESISTANCE..................................................   MORE THAN 100MΩ AT500 VDC
　 DIELECTRIC...........................................................................   FOR 1 MINUTE OR MORE AT 500 VDC
　 TRACKING ERROR...............................................................   -40-0dB<= 3dB
　 SWITCH RATING...................................................................   MORE THAN 500V AC 1A
　 R160,R162 SWITCH RATING.............................................   MORE THAN 1500V AC 1A
　 MECHANICAL SPECIFICATION   　 　 　 　
　 TOTAL ROTATION ANGLE...................................................   300±5° 　
　 BUSHING NUT TIGHTING STRENGTH............................   MORE THAN 7kg
　 SHAFT STOP STRENGTH...................................................   MORE THAN 7kg
　 OPERATING TORQUE FORCE...........................................   20-200 g-cm
　 SHAFT STOP STRENGTH...................................................   MORE THAN 6kgf.-cm/min
　 TERMINAL STRENGTH........................................................   MORE THAN 500g-cm/10±SEC SOLDING
HEAT 300±5°/3SEC 200g-cm/10±1SEC
RESIST CHANGE WITH±2%
　 ROTATION/SLIDING LIFE....................................................   MORE THAN 15000 CYCLES
　 SWITCH LIFE..........................................................................   MORE THAN 10000 CYCLES
　 CLICK POSITION...................................................................   center or 11 .41 positions
　 CLICK TOTQUE.....................................................................   100~400 gf.cm
