TOTAL ROTATION ANGLE
ROTATION TORQUE
SHAFT STOP STRENGTH
SWITCH WORKING ANGLE
SWITCH WORKING TORQUE
SWITCH CIRCUIT
CLICK POSITION
CLICK TORQUE |
120°±5°:F1/F2
tone,balance control
180°±5°:F1/F2 fader control
300°±5°:R1/R2 volume control
outer shaft 30~250 gf.cm
inner shaft 30~250 gf.cm
tuning shaft 100 gf.cm Max .
outer shaft:more than 4 kgf cm/min.
inner shaft:more than 5kgf cm/min.
T12 SERIES: 40°±10°
1,000 gf.cm MAX
S.P.S.T.
center(120°~180°rotation type)
60~450 gf.cm |
T12 series
RATED WATTAGE
RATED VOLTAGE
INSULATION RESISTANCE
DIELECTRIC
SWITCH CONTACT RESISTNACE
SWITCH RATING
TAP POSITION
TRACKING ERROR |
linear tape (B)Other taper
0.05W 0.05W
100V 50V
more than 100MΩ at DC500V
AC 500V,1 Minute
less than 50mΩ
12VDC 3A
50% rotation position
volume control:-40~0dB <= 4dB
tone control: <= 2dB at 50%
rotation position |
