RATED WATTAGE
RATED VOLTAGE
ROTARY NOISE
INSULATION RESISTANCE
WITHSTAND VOLTAGE |
Linear taper(B)
Other taper
0.05W 0.05W
30VDC 30VDC
Less than 47mV
More than 100MΩ at 100V
1 minute at AC 100V |
ROTATION ANGLE
ROTATION TORQUE
SHAFT STOP STRENGTH
LIFE TEST |
220°±5°
20~150gf.cm
1 kgf.cm MAX
15,000 |
|
