TOTAL RESISTANCE
POWER RATING
ROTATION ANGLE
ROTATION TORQUE
INSULATION RESISTANCE
DIELECTRIC
NOISE
ROTATION LIFE
TRACKING ERROR

5-250KΩ±20%
0.03W
270°±5°
10-100gf-cm
DC 100V,100MΩMIN
AC 100V 1 MINUTE
100mV MAX
10,000 CYCLES
-NA-

5-250KΩ±20%
0.03W
270°±5°
10-100gf-cm
DC 100V,100MΩMIN
AC 100V 1 MINUTE
100mV MAX
10,000 CYCLES
-40dB~0dB≤4db
